6.3 Data conversion instructions 6.3.2 BIN, BINP, DBIN, DBINP
: BCD data or head number of the devices where the BCD data is stored (BCD 4/8 digits)
:
Head number of the devices where BIN data will be stored (BIN 16/32 bits)
Function
BIN
Converts BCD data (0 to 9999) at device designated by to BIN data, and stores at the device designated by .
DBIN
Converts BCD data (0 to 99999999) at device designated by to BIN data, and stores at the device designated by .
6.3.2 BIN, BINP Conversion from BCD 4-digit data to BIN data
DBIN, DBINP Co nversion from BCD 8-digit data to BIN data
6.3.2 BIN, BINP, DBIN, DBINP
