Mitsubishi MELSEC-Q/L User Manual

139
OUT
1
2
3
4
5
6
7
8
5.3 Output Instructions 5.3.1 OUT
5.3 Output Instructions
: Number of the device to be turned ON and OFF (bits)
Function
(1) Operation results up to the OUT instruction are output to the designated device.
(a) When Using Bit Devices
(b) When Bit Designation has been Made for Word Device
Operation Error
(1) There is no operation error in the OUT instruction.
Program Example
(1) When using bit devices
[Ladder Mode] [List Mode]
5.3.1 OUT Out (excluding timers, counte rs, and annunciators)
5.3.1 OUT
Setting
Data
Internal Devices
R, ZR
J\
U\G
Zn Constants
Other
DY
Bit Word Bit Word
(Other
than T, C,
or F)
––
Operation Results Coil
OFF OFF
ON ON
Operation Results Bit Designated
OFF 0
ON 1
Basic
Process
High
performance
Redundant Universal LCPU
D0.5
Y35
Bit device number ( )
OUT
D
D
Command
Command
Word device
bit designation ( )
D
D
Step
Instruction
Device
