WXOR, WXORP, DXOR, DXORP
1
2
3
4
4
6
7
8
7.1 Logical operation instructions 7.1.5 WXOR, WXORP, DXOR, DXORP
Program Example
(1) The following program performs an exclusive OR operation on the data at D10 and D20 when XA is ON, and stores the
result at D10.
[Ladder Mode] [List Mode]
[Operation]
(2) The following program compares the bit pattern of the 32-bit data from X20 to X3F with the bit pattern of the data at D9
and D10 when X6 is ON, and stores the number of differing bits at D16.
[Ladder Mode] [List Mode]
[Operation]
Remark
See Page 356, Section 7.5.2 for more information on the DSUMP instruction.
