Mitsubishi MELSEC-Q/L User Manual

133
MPS, MRD, MPP
1
2
3
4
5
6
7
8
5.2 Association Instructions 5.2.2 MPS, MRD, MPP
1. The following shows ladders both using and not using the MPS, MRD, and MPP instructions.
2. The MPS and MPP instructions must be used the same number of times. Failure to observe this will not correctly display
the ladder in the ladder mode of the peripheral device.
Operation Error
(1) There is no operation error in the MPS, MRD, or MPP instruction.
Program Example
(1) A program using the MPS, MRD, and MPP instructions.
[Ladder Mode] [List Mode]
Ladder Using the MPS, MRD and MPP Instructions Ladder not Using MPS, MRD, and MPP Instructions
Y10
X0
X1 X2
X3
X4
Y11
X5
Y12
Y10
X0
X1 X2
X4
Y11
Y12
X0
X1
X3
X0
X1
X5
1)
2)
3) 4)
5)
6)
7)
8)
9)
10)
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Step
Instruction
Device
