7.7 Data Table Operation Instructions 7.7.4 FDEL, FDELP, FINS, FINSP
(2) The following program inserts the data at D0 into the third position at the table R0 to R7 when X10 is turned ON.
[Ladder Mode] [List Mode]
[Operation]
Step
Instruction
Device
R1
R2
R3
R4
Data table
1234
4444
4
-123
5000
0
-3210
R5 0
X10:ON
0 R6
R7
R0
R1
R2
R3
R4
Data table
1234
4444
5
-3210
-123
0
R5
0 R6
R7
R0
D0
Data table
range
5000
