565
SCL2, SCL2P, DSCL2, DSCL2P
1
2
3
4
4
6
7
8
7.13 Data Control Instructions
7.13.5 SCL2, SCL2P, DSCL2, DSCL2P
Operation Error
(1) In any of the following cases, an operation error occurs, the error flag (SM0) turns on, and an error code is stored into
SD0.
Program Example
(1) The following program executes scaling for the scaling conversion data of which the devices specified at D110 and up
are set with the input value specified at D0, and then outputs the data at D200.
[Ladder Mode] [List Mode]
[Operation]
Error
code
Error details
Q00J/
Q00/
Q01
QnH QnPH QnPRH QnU LCPU
4100
The X coordinates are not set in ascending order.
The input value specified in is not within the range of the scaling
conversion data set.
The number of X and Y coordinates of the device specified in is not
within the range from 1 to 32767.
–– –– –– ––
4101
The number of X and Y coordinates of the device specified in
exceeds the specified range.
–– –– –– ––
S1
S2
S2
Step
Instruction
Device
Scaling conversion data component
Setting item Device
Setting contents
Number of coordinate points
X coordinate
Y coordinate
Point 1
Point 2
Point 3
Point 2
Point 4
Point 5
Point 1
Point 3
Point 4
Point 5
D110 K5
D111 K7
D112 K13
D113 K15
D114K18
D115 K20
D116 K-14
D117 K-7
D118 K-15
D119 K-11
D120 K-18
Y
Point 1
(7, -14)
Point 2
(13, -7)
Point 3
(15, -9)
Point 5
(20, -13)
Point 4
(18, -11)
X
D0=11
(Input value)
D200=-9
(
Output value
)
To Next Page
