Mitsubishi MELSEC-Q/L User Manual

58
Category
Instruction Symbol
Symbol Processing Details
Execution
Condition
Number of Basic Steps
Subset
See for Description
Search
MAX
• Searches the data of n points from the
device designated by (S) in 16-bit units,
and stores the maximum value at the
device designated by (D).
4-
Page
371
MAXP
MIN
• Searches the data of n points from the
device designated by (S) in 16-bit units,
and stores the minimum value at the
device designated by (D).
Page
373
MINP
DMAX
• Searches the data of 2n points from the
device designated by (S) in 32-bit units,
and stores the maximum value at the
device designated by (D).
4-
Page
371
DMAXP
DMIN
• Searches the data of 2n points from the
device designated by (S) in 32-bit units,
and stores the minimum value at the
device designated by (D).
Page
373
DMINP
Sort
SORT
• Sorts data of n points from device
designated by (S1) in 16-bit units.
(n x (n-1)/2 scans required)
6-
Page
375
DSORT
• Sorts data of 2n points from device
designated by (S1) in 32-bit units.
(n x (n-1)/2 scans required)
Tota l v a l u e
calculations
WSUM
• Adds 16 bit BIN data of n points from
the device specified by (S), and stores
it in the device specified by (D).
4-
Page
378
WSUMP
DWSUM
• Adds 32 bit BIN data of n points from
the device specified by (S), and stores
it in the device specified by (D).
Page
379
DWSUMP
Calculation
of averages
MEAN
• Calculates the mean of n-point devices
(in 16-bit units) starting from the device
specified by (S), and then stores the
result into the device specified by (D).
4-
Page
381
MEANP
DMEAN
• Calculates the mean of n-point devices
(in 32-bit units) starting from the device
specified by (S), and then stores the
result into the device specified by (D).
DMEANP
MAX nSD
MAXP nSD
MIN nSD
MINP nSD
DMAX nSD
DMAXP nSD
DMIN nSD
DMINP nSD
SORT S2 D1S1
n
D2
· S2: Number of comparisons to be
made during a single run
· D1: Device to be turned ON at the
completion of sort
· D2: For system use
DSORT S1
n
· S2: Number of comparisons to be
made during a single run
· D1: Device to be turned ON at the
completion of sort
· D2: For system use
S2 D1 D2
WSUM nSD
WSUMP nSD
DWSUM nSD
DWSUMP nSD
MEAN SDn
MEANP SDn
DMEAN SDn
DMEANP SDn
