Program Example
(1) This program displays the string stored after D10 on the display unit, when X10 is set to "on".
[Ladder Mode] [List Mode]
[Action]
(2) This program displays "Line-A Working" on the display unit when M0 is set to "on".
[Ladder Mode] [List Mode]
[Action]
(3) This program displays "Line-B stop" on the display unit when X10 is set to "on", and clears the message when X10 is set
to "off".
[Ladder Mode] [List Mode]
[Action]
Instruction
Device
Step
4CH (i)
6E
H (e)
2D
H (A)
20
H (w)
6F
H (r)
6B
H (i)
6E
H (g)
b15 to b8
69
H (L)
65
H (n)
41
H (-)
77
H ( )
72
H (o)
69
H (k)
67
H (n)
00H
D10
D11
D12
D13
D14
D15
D16
D17
Run UMSG
instruction
b7 to b0
Line-A Working
User message
"Line-A Working"
Instruction
Device
Step
"Line-A Working"
60
H
"Line-A Working"
89
H
43
H
93
H
40
H
5E
H
5D
H
b15 to b8
82
H
83
H
83
H
83
H
81
H
89
H
93
H
86
H
92
H
0000
H
Run UMSG
instruction
b7 to b0
User message
Line-A Working
"Line-B stop"
Instruction
Device
Step
"Line-B stop"
X10 set to "off"X10 set to "on"
Line-B stop
User message
