702
D.DDRD, DP.DDRD
Program Example
(1) This program stores data by 10 words starting from D0 in CPU No.2 into W10 or later in host CPU when X0 turns on.
[Ladder Mode] [List Mode]
Caution
(1) Digit specification of bit device is possible for n, , and . Note that when the digit specification of bit device is made to
or , the following conditions must be met.
• Digits are specified by 16 bits (4 digits).
• The start bit device is multiples of 16 (10
H
).
(2) Execute this instruction after checking that the read target CPU is powered on. Not doing so may end up no processing.
(3) If changing a range of the device specified at setting data between after execution of the instruction and turn-on of the
completion device, data to be stored by system (completion status, completion device) cannot be stored normally.
S2
D1
S2
D1
To Next Page
