Appendix 1OPERATION PROCESSING TIME
Appendix 1.2Operation Processing Time of Basic Model QCPU
Appendix 1.2 Operation Processing Time of Basic Model QCPU
The processing time for the individual instructions are shown in the table on the following pages.
Operation processing times can vary substantially depending on the nature of the sources and destinations of the instructions,
and the values contained in the following tables should therefore be taken as a set of general guidelines to processing time
rather than as being strictly accurate.
When using a file resister (ZR), module access device (Un\G , U3En\G0 to G511), and link direct device (Jn\ ), add the
processing time shown in Page 721, Appendix 1.2(6) to that of the instruction.
(1) Sequence instructions
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
LD
LDI
AND
ANI
OR
ORI
X0 0.20 0.16 0.10
D0.0 0.30 0.24 0.15
LDP
LDF
ANDP
ANDF
ORP
ORF
X0
0.30 0.24 0.15
D0.0
ANB
ORB
MPS
MRD
MPP
–– 0.20 0.16 0.10
INV
When not executed
0.20 0.16 0.10
When executed
MEP
MEF
When not executed
0.30 0.24 0.15
When executed
EGP
When not
executed
(OFF OFF)
(ON ON)
0.20 0.16 0.10
When
executed
(OFF ON)
(ON OFF)
EGF
When not
executed
(OFF OFF)
(ON ON)
17 9.5 9.4
When
executed
(OFF ON)
(ON OFF)
18 14 14
OUT
Y
When not
changed
(OFF OFF)
(ON ON)
0.20 0.16 0.10
When
changed
(OFF ON)
(ON OFF)
0.20 0.16 0.10
D0.0
When not
changed
(OFF OFF)
(ON ON)
0.40 0.32 0.20
When
changed
(OFF ON)
(ON OFF)
0.40 0.32 0.20
F
When OFF 24 20 19
When
ON
When displayed 260 210 200
Display completed 205 165 155
