Appendix 1OPERATION PROCESSING TIME Appendix 1.3Operation Processing Time of High Performance Model QCPU/Process CPU/Redundant
CPU
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
LDD =
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.39 0.17 0.17 0.17
ANDD =
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.39 0.17 0.17 0.17
ORD =
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
LDD < >
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ANDD < >
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ORD < >
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
LDD >
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ANDD >
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ORD >
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
LDD < =
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ANDD < =
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ORD < =
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
LDD <
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ANDD <
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ORD <
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
LDD > =
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ANDD > =
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
ORD > =
When not executed 0.39 0.17 0.17 0.17
When executed
In conductive status 0.55 0.24 0.24 0.24
In non-conductive status 0.55 0.24 0.24 0.24
