Mitsubishi MELSEC-Q/L User Manual

742
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
DLIMIT
DLIMITP
–– 11 4.7 4.7 4.7
BAND
BANDP
–– 9.8 4.2 4.2 4.2
DBAND
DBANDP
–– 11 4.9 4.9 4.9
ZONE
ZONEP
–– 9.1 3.9 3.9 3.9
DZONE
DZONEP
–– 11 4.6 4.6 4.6
RSET
RSETP
–– 6.8 2.9 2.9 2.9
QDRSET
QDRSETP
–– 205 88 88 88
QCDSET
QCDSETP
–– 147 63 63 63
DATERD
DATERDP
–– 13 5.5 5.5 5.5
DATEWR
DATEWRP
–– 15 6.4 6.4 6.4
DATE+
DATE+P
No digit increase 13 5.4 5.4 5.4
Digit increase 13 5.4 5.4 5.4
DATE -
DATE - P
No digit increase 12 5.2 5.2 5.2
Digit increase 12 5.2 5.2 5.2
SECOND
SECONDP
–– 10 4.5 4.5 4.5
HOUR
HOURP
–– 12 5.2 5.2 5.2
MSG
1 character 3.0 1.3 1.3 1.3
32 characters 3.0 1.3 1.3 1.3
PKEY
Initial time 20 8.6 8.6 8.6
No reception 19 8.2 8.2 8.2
PSTOP
PSTOPP
–– 79 34 34 34
POFF
POFFP
–– 79 34 34 34
PSCAN
PSCNAP
–– 75 32 32 32
PLOW
PLOWP
–– 80 34 34 ––
WDT
WDTP
–– 5.9 2.6 2.6 2.6
DUTY –– 9.3 4.0 4.0 4.0
ZRRDB
ZRRDBP
–– 7.9 3.4 3.4 3.4
ZRWRB
ZRWRBP
–– 9.4 4.0 4.0 4.0
ADRSET
ADRSETP
–– 4.9 2.1 2.1 2.1
KEY –– 17 7.3 7.3 ––
ZPUSH
ZPUSHP
–– 11 4.7 4.7 4.7
ZPOP
ZPOPP
–– 5.1 2.2 2.2 2.2
EROMWR
EROMWRP
–– –– –– –– ––
