744
(b) Instructions available from function version B
*1: If the processing overlaps those of the other CPUs in a multiple CPU system, the processing time increases by a maximum of
the following time.
*2: In a multiple CPU system, the instruction processing time for the intelligent function module under control of the host CPU is
equal to that for the intelligent function module under control of another CPU.
*3: Products with the first 5 digits of the serial No. "07032" or higher are applicable.
(5) Redundant system instructions (for redundant CPU)
Instruction Condition/Number of Points Processed
Processing Time (µs)
Qn QnH QnPH QnPRH
COM
*1
With auto refresh of
CPU shared memory
Refresh range: 2k words
(0.5k words
assigned equally to all CPUs)
720 660 660 ––
Refresh range: 4k words
(1k words assigned equally to all
CPUs)
860 730 730 ––
Without auto refresh
of CPU shared
memory
–– 43 20 20 20
FROM
*1
Reading from CPU
shared memory of
another CPU
n3 = 1 592929––
n3 = 1000 530 500 500 ––
Reading buffer
memory of intelligent
function module*2
n3 = 1
Main base unit 51 24 24 ––
Extension base unit 54 27 27 ––
n3 =
1000
Main base unit 540 480 480 ––
Extension base unit 1100 1050 1050 ––
S.TO
Writing to CPU shared
memory of host CPU
n3 = 1 ("TO" instruction)
n4 = 1 ("S.TO instruction")
74 33 33 ––
n2 = 256 126 54 54 ––
S (P).DATERD
*3
Reading data of the
expansion clock
–– 25 11 11 11
S (P).DATE+
*3
Expansion clock data
addition operation
–– 38 17 17 17
S (P).DATE-
*3
Expansion clock data
subtraction operation
–– 38 17 17 17
For system having only the main base unit
(Instruction processing time increase) = 0.54 (number of points processed) (number of other CPUs) (µs)
For system including extension base units
(Instruction processing time increase) = 1.30 (number of points processed) (number of other CPUs) (µs)
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
SP.CONTSW –– –– –– –– 9.6
