Appendix 1OPERATION PROCESSING TIME Appendix 1.4Operation Processing Time of Universal Model QCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
COM
CCOM
When selecting I/O refresh only
18.100 89.100 18.100 89.100 18.100 89.100 12.800 79.000
When selecting CC-Link refresh
only (master station side)
33.300 132.000 33.300 132.000 33.300 132.000 24.900 119.000
When selecting CC-Link refresh
only (local station side)
33.300 132.000 33.300 132.000 33.300 132.000 24.900 119.000
• When selecting MELSECNET/
H refresh only (Control station
side)
• When selecting CC-Link IE
Controller Network refresh only
(Control station side)
78.600 231.000 78.600 231.000 78.600 231.000 54.000 212.000
• When selecting MELSECNET/
H refresh only (Normal station
side)
• When selecting CC-Link IE
Controller Network refresh only
(Normal station side)
78.600 231.000 78.600 231.000 78.600 231.000 54.000 212.000
When selecting CC-Link IE Field
Network refresh only (master
station side)
32.000 127.000 32.000 127.000 32.000 127.000 22.000 118.000
When selecting CC-Link IE Field
Network refresh only (local station
side)
32.000 127.000 32.000 127.000 32.000 127.000 22.000 118.000
When selecting intelli auto refresh
only
18.100 89.000 18.100 89.000 18.100 89.000 12.800 79.000
When selecting I/O outside the
group only (Input only)
15.700 71.600 15.700 71.600 15.700 71.600 8.600 76.500
When selecting I/O outside the
group only (Output only)
40.200 152.000 40.200 152.000 40.200 152.000 26.300 135.000
When selecting I/O outside the
group only (Both I/O)
45.800 153.000 45.800 153.000 45.800 153.000 26.100 135.000
When selecting refresh of multiple
CPU high speed transmission
area only
–– –– –– –– –– –– –– ––
When selecting communication
with external devices only
18.200 89.000 18.200 89.000 18.200 89.000 7.250 54.300
FIFW
Number of data points = 0
6.100 14.200 6.100 14.200 6.100 14.200 3.700 10.100
Number of data points = 96
6.100 14.200 6.100 14.200 6.100 14.200 3.800 5.200
FIFR
Number of data points = 0
7.500 15.600 7.500 15.600 7.500 15.600 4.400 5.800
Number of data points = 96
37.000 45.000 37.000 45.000 37.000 45.000 33.500 35.200
FPOP
Number of data points = 0
7.600 15.600 7.600 15.600 7.600 15.600 4.400 10.800
Number of data points = 96
7.600 15.600 7.600 15.600 7.600 15.600 4.400 10.800
FINS
Number of data points = 0
6.900 15.000 6.900 15.000 6.900 15.000 5.000 10.700
Number of data points = 96
36.600 44.700 36.600 44.700 36.600 44.700 4.400 10.900
FDEL
Number of data points = 0
8.000 16.100 8.000 16.100 8.000 16.100 4.900 11.300
Number of data points = 96
37.300 45.500 37.300 45.500 37.300 45.500 34.200 35.900
FROM n1 n2 n3
n3 = 1
17.400 74.700 17.400 74.700 17.400 74.700 12.100 71.300
n3 = 1000
406.000 498.500 406.000 498.500 406.000 498.500 402.600 495.100
DFRO n1 n2 n3
n3 = 1
19.600 85.600 19.600 85.600 19.600 85.600 14.600 81.800
n3 = 500
406.000 498.500 406.000 498.500 406.000 498.500 402.600 495.100
TO n1 n2 n3
n3 = 1
16.400 69.600 16.400 69.600 16.400 69.600 11.700 63.400
n3 = 1000
381.300 471.200 381.300 471.200 381.300 471.200 375.900 464.300
DTO n1 n2 n3
n3 = 1
18.600 85.100 18.600 85.100 18.600 85.100 14.200 78.500
n3 = 500
381.300 471.200 381.300 471.200 381.300 471.200 375.900 464.300
