Appendix 1OPERATION PROCESSING TIME Appendix 1.4Operation Processing Time of Universal Model QCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q03
UD(E)CPU
Q04/Q06
UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Q50/Q100
UDEHCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
NEXT ––
0.940 1.400 0.770 1.200 0.770 1.200 0.770 1.200
BREAK ––
10.400 5.500 9.100 5.000 9.100 5.000 9.100 5.000
RET
Return to original program
2.000 3.000 1.600 2.600 1.600 2.600 1.600 2.600
Return to other program
2.300 3.700 2.000 3.100 2.000 3.100 2.000 3.100
FCALL Pn
Internal file pointer
3.100 4.400 2.700 3.600 2.700 3.600 2.700 3.600
Common pointer
4.000 5.700 3.600 5.100 3.600 5.100 3.600 5.100
FCALL Pn to
––
19.300 21.500 16.500 18.600 16.500 18.600 16.500 18.600
ECALL * Pn
*: Program name
––
70.300 82.300 65.900 77.600 65.900 77.600 65.900 77.600
ECALL * Pn to
*: Program name
––
101.000 114.000 91.800 105.000 91.800 105.000 91.800 105.000
EFCALL * Pn
*: Program name
––
70.700 82.800 66.200 78.100 66.200 78.100 66.200 78.100
EFCALL * Pn to
*: Program name
––
86.500 107.000 78.800 91.600 78.800 91.600 78.800 91.600
XCALL ––
3.800 5.700 3.700 5.200 3.700 5.200 3.700 5.200
S1
S5
S1
S5
S1
