792
Category Instruction Condition (Device)
Processing Time (µs)
Q03
UD(E)CPU
Q04/Q06
UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Q50/Q100
UDEHCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
SCL
SM750
= ON
Point No.1
< <
Point No.2
13.200 23.600 12.300 22.500 12.300 22.500 12.300 22.500
Point No.9
< <
Point No.10
13.300 23.600 12.600 22.700 12.600 22.700 12.600 22.700
SM750
= OFF
Point No.1
< <
Point No.2
12.000 23.100 11.400 22.200 11.400 22.200 11.400 22.200
Point No.9
< <
Point No.10
14.100 25.300 12.800 23.900 12.800 23.900 12.800 23.900
DSCL
SM750
= ON
Point No.1
< <
Point No.2
12.800 23.800 11.900 23.000 11.900 23.000 11.900 23.000
Point No.9
< <
Point No.10
12.900 23.900 12.100 23.000 12.100 23.000 12.100 23.000
SM750
= OFF
Point No.1
< <
Point No.2
11.500 22.400 10.900 21.500 10.900 21.500 10.900 21.500
Point No.9
< <
Point No.10
13.800 24.900 12.700 23.600 12.700 23.600 12.700 23.600
SCL2
SM750
= ON
Point No.1
< <
Point No.2
12.700 24.200 11.900 23.300 11.900 23.300 11.900 23.300
Point No.9
< <
Point No.10
12.900 24.600 12.100 23.300 12.100 23.300 12.100 23.300
SM750
= OFF
Point No.1
< <
Point No.2
12.300 23.400 11.500 22.600 11.500 22.600 11.500 22.600
Point No.9
< <
Point No.10
13.700 25.000 12.600 23.900 12.600 23.900 12.600 23.900
DSCL2
SM750
= ON
Point No.1
< <
Point No.2
12.600 23.800 11.800 22.900 11.800 22.900 11.800 22.900
Point No.9
< <
Point No.10
13.000 23.900 12.200 22.800 12.200 22.800 12.200 22.800
SM750
= OFF
Point No.1
< <
Point No.2
11.500 22.400 11.000 21.400 11.000 21.400 11.000 21.400
Point No.9
< <
Point No.10
13.900 24.900 12.800 23.600 12.800 23.600 12.800 23.600
S1
S2
D
S1
S1
S1
S1
S1
S2
D
S1
S1
S1
S1
S1
S2
D
S1
S1
S1
S1
S1
S2
D
S1
S1
S1
S1
