794
Category Instruction Condition (Device)
Processing Time (µs)
Q03
UD(E)CPU
Q04/Q06
UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Q50/Q100
UDEHCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Application
instruction
LDDT>
Comparison
of specified
date
In conductive status
7.400 11.400 6.800 10.900 6.800 10.900 6.800 10.900
In non-conductive status
7.400 11.600 6.800 10.900 6.800 10.900 6.800 10.900
Comparison
of current
date
In conductive status
5.900 10.000 5.500 9.700 5.500 9.700 5.500 9.700
In non-conductive status
5.900 10.100 5.500 9.700 5.500 9.700 5.500 9.700
ANDDT>
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
date
In conductive status
7.200 11.400 6.500 10.700 6.500 10.700 6.500 10.700
In non-conductive status
7.200 11.400 6.500 10.700 6.500 10.700 6.500 10.700
Comparison
of current
date
In conductive status
5.700 9.900 5.300 9.300 5.300 9.300 5.300 9.300
In non-conductive status
5.700 9.900 5.300 9.300 5.300 9.300 5.300 9.300
ORDT>
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
date
In conductive status
7.400 11.500 6.700 10.800 6.700 10.800 6.700 10.800
In non-conductive status
7.400 11.500 6.700 10.800 6.700 10.800 6.700 10.800
Comparison
of current
date
In conductive status
5.900 10.000 5.400 9.600 5.400 9.600 5.400 9.600
In non-conductive status
5.900 10.000 5.400 9.600 5.400 9.600 5.400 9.600
LDDT<=
Comparison
of specified
date
In conductive status
7.400 11.400 6.800 10.900 6.800 10.900 6.800 10.900
In non-conductive status
7.400 11.600 6.800 10.900 6.800 10.900 6.800 10.900
Comparison
of current
date
In conductive status
5.900 10.000 5.500 9.700 5.500 9.700 5.500 9.700
In non-conductive status
5.900 10.100 5.500 9.700 5.500 9.700 5.500 9.700
ANDDT<=
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
date
In conductive status
7.200 11.400 6.500 10.700 6.500 10.700 6.500 10.700
In non-conductive status
7.200 11.400 6.500 10.700 6.500 10.700 6.500 10.700
Comparison
of current
date
In conductive status
5.700 9.900 5.300 9.300 5.300 9.300 5.300 9.300
In non-conductive status
5.700 9.900 5.300 9.300 5.300 9.300 5.300 9.300
ORDT<=
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
date
In conductive status
7.400 11.500 6.700 10.800 6.700 10.800 6.700 10.800
In non-conductive status
7.400 11.500 6.700 10.800 6.700 10.800 6.700 10.800
Comparison
of current
date
In conductive status
5.900 10.000 5.400 9.600 5.400 9.600 5.400 9.600
In non-conductive status
5.900 10.000 5.400 9.600 5.400 9.600 5.400 9.600
LDDT<
Comparison
of specified
date
In conductive status
7.400 11.400 6.800 10.900 6.800 10.900 6.800 10.900
In non-conductive status
7.400 11.600 6.800 10.900 6.800 10.900 6.800 10.900
Comparison
of current
date
In conductive status
5.900 10.000 5.500 9.700 5.500 9.700 5.500 9.700
In non-conductive status
5.900 10.100 5.500 9.700 5.500 9.700 5.500 9.700
ANDDT<
When not executed
0.008 0.038 0.038 0.038
Comparison
of specified
date
In conductive status
7.200 11.400 6.500 10.700 6.500 10.700 6.500 10.700
In non-conductive status
7.200 11.400 6.500 10.700 6.500 10.700 6.500 10.700
Comparison
of current
date
In conductive status
5.700 9.900 5.300 9.300 5.300 9.300 5.300 9.300
In non-conductive status
5.700 9.900 5.300 9.300 5.300 9.300 5.300 9.300
