Appendix 1OPERATION PROCESSING TIME Appendix 1.4Operation Processing Time of Universal Model QCPU
(b) When using Q03UD(E)CPU, Q04UD(E)HCPU, Q06UD(E)HCPU, Q10UD(E)HCPU, Q13UD(E)HCPU,
Q20UD(E)HCPU, Q26UD(E)HCPU, Q50UDEHCPU and Q100UDEHCPU
Device name data
Device
Specification
Location
Processing Time (µs)
Q03UD(E)
CPU
Q04/Q06UD(E)H
CPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Q50/Q100UDEH
CPU
File register (R)
When standard
RAM is used
Bit
Source 0.100 0.048 0.048 0.048
Destination 0.100 0.038 0.038 0.038
Word
Source 0.100 0.048 0.048 0.048
Destination 0.100 0.038 0.038 0.038
Double
word
Source 0.200 0.095 0.095 0.095
Destination 0.200 0.086 0.086 0.086
When SRAM
card is used
(Q2MEM-1MBS,
Q2MEM-2MBS)
Bit
Source 0.220 0.200 0.200 0.200
Destination 0.180 0.162 0.162 0.162
Word
Source 0.220 0.200 0.200 0.200
Destination 0.180 0.162 0.162 0.162
Double
word
Source 0.440 0.399 0.399 0.399
Destination 0.380 0.361 0.361 0.361
When SRAM
card is used
(Q3MEM-4MBS,
Q3MEM-8MBS)
Bit
Source 0.160 0.152 0.152 0.152
Destination 0.140 0.133 0.133 0.133
Word
Source 0.160 0.152 0.152 0.152
Destination 0.140 0.133 0.133 0.133
Double
word
Source 0.320 0.304 0.304 0.304
Destination 0.300 0.295 0.295 0.295
File register
(ZR)/
Extended data
register (D)/
Extended link
register (W)
When standard
RAM is used
Bit
Source 0.120 0.057 0.057 0.057
Destination 0.120 0.048 0.048 0.048
Word
Source 0.120 0.057 0.057 0.057
Destination 0.120 0.048 0.048 0.048
Double
word
Source 0.220 0.105 0.105 0.105
Destination 0.220 0.095 0.095 0.095
When SRAM
card is used
(Q2MEM-1MBS,
Q2MEM-2MBS)
Bit
Source 0.240 0.209 0.209 0.209
Destination 0.200 0.171 0.171 0.171
Word
Source 0.240 0.209 0.209 0.209
Destination 0.200 0.171 0.171 0.171
Double
word
Source 0.460 0.409 0.409 0.409
Destination 0.400 0.371 0.371 0.371
When SRAM
card is used
(Q3MEM-4MBS,
Q3MEM-8MBS)
Bit
Source 0.180 0.162 0.162 0.162
Destination 0.160 0.143 0.143 0.143
Word
Source 0.180 0.162 0.162 0.162
Destination 0.160 0.143 0.143 0.143
Double
word
Source 0.340 0.314 0.314 0.314
Destination 0.320 0.304 0.304 0.304
Module access device
(Un\G , U3En\G0 to G4095)
Bit
Source 11.700 11.200 11.200 11.200
Destination 15.400 15.300 15.300 15.300
Word
Source 9.460 9.410 9.410 9.410
Destination 19.000 19.000 19.000 19.000
Double
word
Source 11.000 10.900 10.900 10.900
Destination 18.800 18.700 18.700 18.700
Link direct device
(Jn\ )
Bit
Source 32.700 31.300 31.300 31.300
Destination 52.300 51.800 51.800 51.800
Word
Source 30.600 30.100 30.100 30.100
Destination 28.900 28.400 28.400 28.400
Double
word
Source 38.900 38.400 38.400 38.400
Destination 34.800 34.300 34.300 34.300
