Appendix 1OPERATION PROCESSING TIME Appendix 1.5Operation Processing Time of LCPU
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Basic
instruction
AND$< >
When not executed
0.120 0.0285
When executed
In conductive status
5.300 16.400 3.900 7.300
In non-conductive status
5.300 16.400 3.900 7.300
OR$< >
When not executed
0.120 0.0285
When executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
LD$>
In conductive status
5.600 17.100 4.200 8.200
In non-conductive status
5.600 17.100 4.200 8.200
AND$>
When not executed
0.120 0.0285
When executed
In conductive status
5.300 16.400 3.900 7.300
In non-conductive status
5.300 16.400 3.900 7.300
OR$>
When not executed
0.120 0.0285
When executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
LD$<=
In conductive status
5.600 17.100 4.200 8.200
In non-conductive status
5.600 17.100 4.200 8.200
AND$<=
When not executed
0.120 0.0285
When executed
In conductive status
5.300 16.400 3.900 7.300
In non-conductive status
5.300 16.400 3.900 7.300
OR$<=
When not executed
0.120 0.0285
When executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
LD$<
In conductive status
5.600 17.100 4.200 8.200
In non-conductive status
5.600 17.100 4.200 8.200
AND$<
When not executed
0.120 0.0285
When executed
In conductive status
5.300 16.400 3.900 7.300
In non-conductive status
5.300 16.400 3.900 7.300
OR$<
When not executed
0.120 0.0285
When executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
LD$>=
In conductive status
5.600 17.100 4.200 8.200
In non-conductive status
5.600 17.100 4.200 8.200
AND$>=
When not executed
0.120 0.0285
When executed
In conductive status
5.300 16.400 3.900 7.300
In non-conductive status
5.300 16.400 3.900 7.300
OR$>=
When not executed
0.120 0.0285
When executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
