Appendix 1OPERATION PROCESSING TIME Appendix 1.5Operation Processing Time of LCPU
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Application
instruction
ANDDT=
When not executed
0.160 0.038
Comparison
of specified
date
In conductive status
7.300 14.000 6.500 10.700
In non-conductive status
7.300 14.000 6.500 10.700
Comparison
of current
date
In conductive status
6.100 12.700 5.300 9.300
In non-conductive status
6.100 12.700 5.300 9.300
ORDT=
When not executed
0.160 0.038
Comparison
of specified
date
In conductive status
7.400 14.400 6.700 10.800
In non-conductive status
7.400 14.400 6.700 10.800
Comparison
of current
date
In conductive status
6.000 12.800 5.400 9.600
In non-conductive status
6.000 12.800 5.400 9.600
LDDT <>
Comparison
of specified
date
In conductive status
7.700 14.200 6.800 10.900
In non-conductive status
7.700 14.200 6.800 10.900
Comparison
of current
date
In conductive status
6.400 12.800 5.500 9.700
In non-conductive status
6.400 12.800 5.500 9.700
ANDDT<>
When not executed
0.160 0.038
Comparison
of specified
date
In conductive status
7.300 14.000 6.500 10.700
In non-conductive status
7.300 14.000 6.500 10.700
Comparison
of current
date
In conductive status
6.100 12.700 5.300 9.300
In non-conductive status
6.100 12.700 5.300 9.300
ORDT<>
When not executed
0.160 0.038
Comparison
of specified
date
In conductive status
7.400 14.400 6.700 10.800
In non-conductive status
7.400 14.400 6.700 10.800
Comparison
of current
date
In conductive status
6.000 12.800 5.400 9.600
In non-conductive status
6.000 12.800 5.400 9.600
LDDT>
Comparison
of specified
date
In conductive status
7.700 14.200 6.800 10.900
In non-conductive status
7.700 14.200 6.800 10.900
Comparison
of current
date
In conductive status
6.400 12.800 5.500 9.700
In non-conductive status
6.400 12.800 5.500 9.700
ANDDT>
When not executed
0.160 0.038
Comparison
of specified
date
In conductive status
7.300 14.000 6.500 10.700
In non-conductive status
7.300 14.000 6.500 10.700
Comparison
of current
date
In conductive status
6.100 12.700 5.300 9.300
In non-conductive status
6.100 12.700 5.300 9.300
ORDT>
When not executed
0.160 0.038
Comparison
of specified
date
In conductive status
7.400 14.400 6.700 10.800
In non-conductive status
7.400 14.400 6.700 10.800
Comparison
of current
date
In conductive status
6.000 12.800 5.400 9.600
In non-conductive status
6.000 12.800 5.400 9.600
