Appendix 1OPERATION PROCESSING TIME Appendix 1.5Operation Processing Time of LCPU
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU, L02CPU-P L26CPU-BT, L26CPU-PBT
Min. Max. Min. Max.
Application
instruction
ORDT>=
When not executed
0.160 0.038
Comparison
of specified
date
In conductive status
7.400 14.400 6.700 10.800
In non-conductive status
7.400 14.400 6.700 10.800
Comparison
of current
date
In conductive status
6.000 12.800 5.400 9.600
In non-conductive status
6.000 12.800 5.400 9.600
LDTM=
Comparison
of specified
clock
In conductive status
7.600 14.000 6.700 10.800
In non-conductive status
7.600 14.000 6.700 10.800
Comparison
of current
clock
In conductive status
6.200 12.700 5.400 9.500
In non-conductive status
6.200 12.700 5.400 9.500
ANDTM=
When not executed
0.160 0.038
Comparison
of specified
clock
In conductive status
7.200 13.900 6.300 10.800
In non-conductive status
7.200 13.900 6.300 10.800
Comparison
of current
clock
In conductive status
5.900 12.500 5.100 9.500
In non-conductive status
5.900 12.500 5.100 9.500
ORTM=
When not executed
0.160 0.038
Comparison
of specified
clock
In conductive status
7.300 14.100 6.600 10.800
In non-conductive status
7.300 14.100 6.600 10.800
Comparison
of current
clock
In conductive status
6.000 12.700 5.300 9.500
In non-conductive status
6.000 12.700 5.300 9.500
LDTM<>
Comparison
of specified
clock
In conductive status
7.600 14.000 6.700 10.800
In non-conductive status
7.600 14.000 6.700 10.800
Comparison
of current
clock
In conductive status
6.200 12.700 5.400 9.500
In non-conductive status
6.200 12.700 5.400 9.500
ANDTM<>
When not executed
0.160 0.038
Comparison
of specified
clock
In conductive status
7.200 13.900 6.300 10.800
In non-conductive status
7.200 13.900 6.300 10.800
Comparison
of current
clock
In conductive status
5.900 12.500 5.100 9.500
In non-conductive status
5.900 12.500 5.100 9.500
ORTM<>
When not executed
0.160 0.038
Comparison
of specified
clock
In conductive status
7.300 14.100 6.600 10.800
In non-conductive status
7.300 14.100 6.600 10.800
Comparison
of current
clock
In conductive status
6.000 12.700 5.300 9.500
In non-conductive status
6.000 12.700 5.300 9.500
LDTM>
Comparison
of specified
clock
In conductive status
7.600 14.000 6.700 10.800
In non-conductive status
7.600 14.000 6.700 10.800
Comparison
of current
ciock
In conductive status
6.200 12.700 5.400 9.500
In non-conductive status
6.200 12.700 5.400 9.500
