7. PARAMETERS
7 - 7
No. Symbol Name
Initial
value
Unit
Control
mode
CP CL
PC66 LPSPL Mark detection range + (lower three digits) 0 10
STM
[μm]/
10
(STM-4)
[inch]/
10
-3
[degree]/
[pulse]
PC67 LPSPH Mark detection range + (upper three digits) 0 10
STM
[μm]/
10
(STM-4)
[inch]/
10
-3
[degree]/
[pulse]
PC68 LPSNL Mark detection range - (lower three digits) 0 10
STM
[μm]/
10
(STM-4)
[inch]/
10
-3
[degree]/
[pulse]
PC69 LPSNH Mark detection range - (upper three digits) 0 10
STM
[μm]/
10
(STM-4)
[inch]/
10
-3
[degree]/
[pulse]
PC70 *SNOM Modbus RTU communication station number setting 0
PC71 *COPF Function selection C-F 0040h
PC72 *COPG Function selection C-G 0000h
PC73 ERW Error excessive warning level 0 [rev]
PC74 For manufacturer setting 0000h
PC75 0000h
PC76 0000h
PC77 0000h
PC78 0000h
PC79 0000h
PC80 0000h
7.1.4 I/O setting parameters ([Pr. PD_ _ ])
POINT
The following parameter cannot be used in the positioning mode.
[Pr. PD03 Input device selection 1L]
[Pr. PD11 Input device selection 5L]
[Pr. PD13 Input device selection 6L]
[Pr. PD17 Input device selection 8L]
[Pr. PD19 Input device selection 9L]
[Pr. PD43 Input device selection 11L]
[Pr. PD45 Input device selection 12L]
