General-Purpose AC Servo
MR-JE-_A SERVO AMPLIFIER INSTRUCTION MANUAL(POSITIONING MODE)
HEAD OFFICE: TOKYO BLDG MARUNOUCHI TOKYO 100-8310
MODEL
General-Purpose Interface AC Servo
1CW707
MR-JE-_A
SERVO AMPLIFIER
INSTRUCTION MANUAL
(POSITIONING MODE)
MR-JE-A
INSTRUCTIONMANUAL(ITIGIME)
C
C

Table of Contents

Questions and Answers

  • P
    Philip PearsonAug 9, 2025
    What to do if Mitsubishi Amplifier servo motor does not rotate?
    • J
      Jennifer McculloughAug 9, 2025
      If your Mitsubishi Amplifier's servo motor doesn't rotate, verify the on/off status of the input signal using the external I/O signal display, paying attention to LSP, LSN, and ST1. Also, examine [Pr. PA11 Forward rotation torque limit] and [Pr. PA12 Reverse rotation torque limit] if the torque limit level is too low for the load torque. If TLA (Analog torque limit) is usable, check the input voltage on the status display. Finally, check the on/off status of input signal DOG with the external I/O signal display if the proximity dog is set incorrectly.
  • B
    Brian AliAug 16, 2025
    What to do if Mitsubishi Amplifier servo motor shaft is not servo-locked?
    • M
      Mary CarterAug 16, 2025
      If the servo motor shaft of your Mitsubishi Amplifier is not servo-locked, first check the display to see if the servo amplifier is ready to operate, as the SON (Servo-on) may not be input due to a wiring mistake. Next, check the external I/O signal indication to see if SON (Servo-on) is on, in case 24 V DC power is not supplied to DICOM.
  • H
    Heather WaltersAug 25, 2025
    How to fix large rotation ripples at low speed on Mitsubishi MR-JE-100A Amplifier?
    • L
      Logan YoungAug 25, 2025
      If you observe large rotation ripples (speed fluctuations) at low speed in your Mitsubishi Amplifier, it might be due to a gain adjustment fault or a large load inertia moment causing the servo motor shaft to oscillate. To address this, make gain adjustments by increasing the auto tuning response level and repeating acceleration and deceleration several times to complete auto tuning. If the servo motor can be driven safely, repeat acceleration and deceleration three times or more to complete the auto tuning.
  • B
    Brian SchneiderAug 31, 2025
    What to do if Mitsubishi Amplifier 7-segment LED display does not turn on?
    • S
      stephenwangAug 31, 2025
      If the 7-segment LED display on your Mitsubishi Amplifier does not turn on or blinks, it could be due to a power supply voltage fault or a malfunctioning servo amplifier. Also, the power supply of CN1, CN2 or CN3 cabling or encoder cabling could be shorted, or the encoder might be malfunctioning. Try disconnecting CN1, CN2 and CN3 connectors one by one to see if that solves the problem.

Summary

Safety Instructions

General Safety Instructions

Provides essential safety guidelines for operating the equipment correctly and safely.

FUNCTIONS AND CONFIGURATION

1.1 For proper use of the positioning mode

Explains the proper usage and configuration for the positioning mode.

1.4 Configuration including peripheral equipment

SIGNALS AND WIRING

2.1 I;O signal connection example

Illustrates connection examples for I/O signals, crucial for system integration.

2.2 Connectors and pin assignment

DISPLAY AND OPERATION SECTIONS

3.1.4 Alarm mode

Details how to interpret and manage alarms for fault resolution.

3.1.5 Point table setting

3.1.6 Parameter mode

HOW TO USE THE POINT TABLE

4.1 Startup

4.1.3 Test operation

4.1.4 Parameter setting

4.2 Automatic operation mode

4.4 Home position return mode

Describes various methods and parameters for establishing a home position.

HOW TO USE THE PROGRAM

5.1 Startup

5.1.6 Troubleshooting at start-up

Provides guidance on resolving common issues encountered during initial setup.

5.2 Program operation method

5.4 Home position return mode

Describes different home position return methods and their configurations.

PARAMETERS

7.1.1 Basic setting parameters ([Pr. PA_ _ ])

Details essential parameters for servo amplifier configuration and operation.

7.1.2 Gain;filter setting parameters ([Pr. PB_ _ ])

7.1.4 I;O setting parameters ([Pr. PD_ _ ])

7.1.7 Positioning control parameters ([Pr. PT_ _ ])

Details parameters crucial for controlling positioning operations and home position return.

TROUBLESHOOTING

8.2 Alarm list

Lists all possible alarms, their details, stop methods, and deactivation procedures.

8.3 Warning list

Lists all possible warnings, their details, and stop methods.

Mitsubishi MR-JE-100A Specifications

General IconGeneral
TypeAC Servo Amplifier
ModelMR-JE-100A
SeriesMR-JE
Rated Output1.0 kW
Weight1.5 kg
Output Current6.0 A
Input Power Supply200-230VAC, 50/60Hz
Feedback SystemIncremental encoder
Protection FunctionsOvercurrent, Overvoltage, Overheat, Encoder Error
Control MethodSine Wave PWM, Current Control System
