1
OVERVIEW
1.1 Features
1 - 16
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
GENERAL
SPECIFICATIONS
4
HARDWARE
SPECIFICATIONS OF
THE CPU MODULE
5
POWER SUPPLY
MODULE
6
BASE UNIT AND
EXTENSION CABLE
7
MEMORY CARD AND
BATTERY
8
CPU MODULE START-
UP PROCEDURES
(7) Connection of up to 7 extension base units.
The Q Series CPU module can connect extension base units for the number of stages
shown in Table1.13.
* 1 : Redundant CPU whose first 5 digits of serial No. is "09012" or later.
Also, the extension base unit cannot be connected to the Redundant CPU whose first 5 digits
ofserial No. is "09011" or earlier. Therefore, the number of mountable modules is up to 11.
The overall distance of the extension cables is up to 13.2m allowing highly flexible
extension base unit layout.
(8) Memory extension
Note1.1
by memory cardNote1
The Q Series CPU module has a memory card installation connector to which a
memory card of 32 Mbytes max. can be connected (32 Mbytes are available when an
ATA card is used).
When a memory card of large capacity is installed, large files can be managed,
enabling setting comments to all data devices and storing the past programs in the
memory as they are in the form of the corrected histories.
Even if a memory card is not installed, a program can be stored onto the standard
ROM built in the CPU module, and file registers can be handled by the standard RAM.
POINT
For the High Performance model QCPU, the number of usable file register points
is different depending on the functional version and serial number.
For details, refer to Appendix 2.2.
Table1.13 Maximum number of extension stages, i.e., extension base units
Item
Max. number of extension
stages
Max. number of modules
installed
Basic model
QCPU
Q00JCPU 2 stages 16 modules
Q00CPU, Q01CPU 4 stages 24 modules
Universal model
QCPU
Q02UCPU 4 stages 36 modules
Q03UDCPU, Q03UDECPU,
Q04UDHCPU,Q04UDEHCPU,
Q06UDHCPU,Q06UDEHCPU,
Q13UDHCPU, Q13UDEHCPU,
Q26UDHCPU, Q26UDEHCPU
7 stages 64 modules
High Performance model QCPU
Process CPU
Redundant CPU
*1
7 stages 63 modules
Note1
Basic
Note1.1
Memory cards are not available for the Basic model QCPU.
Basic
Note1.1
