4 - 14
4 INSTALLATION AND WIRING
(b) Removal
Top face of battery holder
Battery lead
connector
(Battery side)
Battery connector
(Q170MCPU side)
MITSUBISHI
LITHIUM BATTERY
1)
2)
3)
(Note)
END
4)
Battery holder
Battery holder fixing tab
Motion controller
Pull
3)
(Note): Do not pull on the lead wire forcibly to remove the connector.
1)
3)
4)
2)
Remove the battery lead connector
and battery connector for Motion
controller.
Push the battery holder fixing tab.
Pull the battery holder while
pushing the battery holder fixing
tab, and remove the holder from
the Motion controller.
Battery disconnection
prevention hook
Push
Move the connector away from the
battery disconnection prevention
hook, and then remove it by pulling
straight out.
To Next Page
