8.
8 - 35
DEBUGGING FUNCTION
8.6 Status Latch Function
This function collects the data of devices at designated moment.
This function is used to retain the statuses of devices used in a program at designated
moment during debugging.
(1) Function
(a) Status latch stores the device statuses at designated moment in a status latch
file of a memory card.
(b) The status latch file stores the status latch condition and status latch execution
data for status latch execution.
Saving the device statuses can be executed in the following case.
• When executing SLT instruction in a program
• When specifying a status latch start at GPP functions
• When the conditions of the set devices and step Nos. are met
(c) The status latch results show the bit device ON/OFF statuses and word devices
values at designated moment.
POINT
When executing status latch function, a memory card is required.
Application
Function Description
