Mitsubishi Q2ACPU User Manual

App - 5
APPENDICES
Appendix 1.2 Basic Instructions
(1) Comparison operation instructions
Classification Symbol Description
16-bit data
comparison
• Conductive status when (S1) = (S2)
• Non-conductive status when (S1) (S2)
• Conductive status when (S1) (S2)
• Non-conductive status when (S1) = (S2)
• Conductive status when (S1) (S2)
• Non-conductive status when (S1) (S2)
• Conductive status when (S1) (S2)
• Non-conductive status when (S1) (S2)
• Conductive status when (S1) (S2)
• Non-conductive status when (S1) (S2)
• Conductive status when (S1) (S2)
• Non-conductive status when (S1) (S2)
32-bit data
comparison
• Conductive status when (S1 + 1, S1) = (S2 + 1, S2)
• Non-conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Non-conductive status when (S1 + 1, S1) = (S2 + 1, S2)
• Conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Non-conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Non-conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Non-conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Conductive status when (S1 + 1, S1) (S2 + 1, S2)
• Non-conductive status when (S1 + 1, S1) (S2 + 1, S2)
