BASE UNIT AND EXTENSION CABLE
17 BASE UNIT AND EXTENSION CABLE
This section explains the specifications of the base units (the main and extension base
units) and extension cables available for the systems, and the application standards for
use of extension base units.
17.1 Specifications of Base Units
(1) Main base unit specifications
(2) Extension base unit specifications
*1 1 For the attachment of the dustproof cover, refer to Section 19.6.
Item
Model Name
A32B A32B-S1 A35B A38B/A38HB/A38HBEU
I/O module
installation range
2 modules can be installed.
5 modules can be
installed.
8 modules can be
installed.
Extension possibility Not extendable Extendable Extendable Extendable
Installation hole size
6 bell-shaped holes (for M5 screws)
External dimensions
247mm (9.6inch) 250mm
(9.8inch) 29mm (1.1inch)
268mm (10.5inch) 250mm
(9.8inch) 29mm (1.1inch)
382mm (14.9inch) 250mm
(9.8inch) 29mm (1.1inch)
480mm (18.7inch) 250mm
(9.8inch) 29mm (1.1inch)
Weight 0.96kg 1.3kg 1.5kg 1.9kg
Item
Model Name
A62B A65B A68B A52B A55B A58B
I/O module
installation range
2 modules can
be installed.
5 modules can
be installed.
8 modules can
be installed.
2 modules can
be installed.
5 modules can
be installed.
8 modules can
be installed.
Power supply module
loading
Power supply module required
Not required. (See .)
Installation hole size
6 bell-shaped holes (for M5 screws) 6 bell-shaped holes (for M5 screws)
Terminal screw size –
M4 0.7 6 (FG terminal)
Applicable wire size –
0.75 to 2mm
2
Applicable solderless
terminal
–
(V)1.25-4, (V)1.25-YS4, (V)2-YS4A
Applicable tightening torque: 78 to 118N cm
External dimensions
283mm (11.0inch)
250mm (9.8inch)
29mm (1.1inch)
352mm (13.7inch)
250mm (9.8inch)
29mm (1.1inch)
466mm (18.2inch)
250mm (9.8inch)
29mm (1.1inch)
183mm (7.1inch)
250mm (9.8inch)
29mm (1.1inch)
297mm (11.6inch)
250mm (9.8inch)
29mm (1.1inch)
411mm (16.0inch)
250mm (9.8inch)
29mm (1.1inch)
Weight 1.1kg 1.4kg 1.9kg 1.0kg 1.2kg 1.7kg
Accessory – *1 Dustproof cover (for I/O module): 1 pc.
