8 - 41

DEBUGGING FUNCTION

8.7 Step Operation

This function runs one step or one part of a program, runs a program with a part skipped.

This function is used to determine the causes of faults during debugging.

This function can only be used when the CPU module is set to STEP-RUN.

The step operation function provides the following three functions. For explanations of

each function, refer to Section 8.7.1 through Section 8.7.3.

• Step execution

• Partial execution

• Skip execution

Application

Function Description
