PARAMETER LIST
13 PARAMETER LIST
The parameters set for the QnACPU are listed in the table below.
For details on each parameter, refer to the section or reference manual indicated.
Item Parameter No. Description
PLC name –
Set labels and/or comments for peripheral devices on the CPU
module.
This setting does not affect CPU module operation.
Label 0000
H Set a label for the CPU module.
Comment 0001
H Set a comment for the CPU module.
PLC system –
Make various settings that are required for the CPU module
system.
Timer limit setting
Low-speed timer
1000
H Set the low-speed or high-speed timer limit.
High-speed timer
RUN-PAUSE contacts 1000
H Set the contact to control RUN/PAUSE of the CPU module.
Remote reset 1002
H Enable or disable the remote reset operation.
Output at STOP RUN
1003
H Set the output mode for switching from STOP to RUN.
Common pointer No. 1005
H Set the first common pointer number.
General data processing 1006
H
Set the number of modules that are processed in one general data
processing.
Points occupied by empty slot 1007
H Set the number of points occupied by empty slots.
System interrupt
Interrupt counter
1008
H
Set the first interrupt counter number, and the fixed scan interval for
the interrupt pointer.
Fixed scan interval
PLC file – Set various kinds of files used by the CPU module.
File register 1100
H Set a file register file to be used.
Comment file used in a command 1101
H Set a comment file used in an instruction.
Initial device value 1102
H Set a file for initial device values to be used.
File for local device 1103
H Set a file for local devices to be used.
