7.
7 - 1
AUTO REFRESH FUNCTION
7 AUTO REFRESH FUNCTION
7.1 For MELSECNET/MINI-S3
By setting link information, I/O storage device, etc. of the MELSECNET/MINI-S3 to the
parameters, the module automatically communicates with the buffer memory area for the
batch refresh send/received data of the type AJ71PT32-S3 MELSECNET/MINI-S3 master
module (abbreviated as the MINI master module hereafter).
The settings are made on the MELSECNET/MINI setting in the parameter mode of GPP
function.
Sequence programs can be created using the I/O devices allocated to send/received by
the MELSECNET/MINI-S3 setting. (The FROM/TO instructions are not required.)
