12 - 3

12. OVERVIEW OF PROCESSING PERFORMED BY THE QnACPU

The following shows the flow of operation processing when a PLC is powered ON, when a

CPU module is reset, or when the RUN/STOP key switch of a CPU module is switched

from STOP to RUN.

POINT

For the QnACPU, all execution types need not be set.

Use initial execution type, low-speed execution type, and standby type programs

marked with asterisks if required.
