12. OVERVIEW OF PROCESSING PERFORMED BY THE QnACPU

(3) END processing

When execution of all initial execution type programs is completed, END processing

is performed and a scan execution type program is executed from the next scan.

POINT

* Instructions that contain a completion device cannot be used in initial execution

type programs.
