Mitsubishi Q2ACPU User Manual

22 - 31
22. TROUBLE SHOOTING
3200
[SFC PARA. ERROR]
The parameter setting is illegal.
• Though Block 0 was set to "Automatic start" in
the SFC setting of the PLC parameter dialog box,
Block 0 does not exist.
■Collateral informationmmon
• Common Information:File name
• Individual Information:Parameter number
■Diagnostic Timing
• STOP RUN
Read the common information of the error using
the peripheral device, check error step
corresponding to its numerical value (program error
location), and correct the problem.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
QnA
3201
[SFC PARA. ERROR]
The block parameter setting is illegal.
■Collateral informationmmon
• Common Information:File name
• Individual Information:Parameter number
■Diagnostic Timing
• STOP RUN
3202
[SFC PARA. ERROR]
The number of step relays specified in the device
setting of the PLC parameter dialog box is less than
that used in the program.
■Collateral informationmmon
• Common Information:File name
• Individual Information:Parameter number
■Diagnostic Timing
• STOP RUN
3203
[SFC PARA. ERROR]
The execution type of the SFC program specified in
the program setting of the PLC parameter dialog
box is other than scan execution.
■Collateral informationmmon
• Common Information:File name
• Individual Information:Parameter number
■Diagnostic Timing
• At power ON/At reset/STOP RUN
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
*3 The diagnostic timing of CPU modules except for Universal QCPU can be performed only when switching the CPU modules to run.
