App - 13

APPENDICES

Gray code

BIN conversion

2's complement

Block conversion

• Converts n points of BIN data from (S) to BCD data in a batch and

stores the result to devices starting from (D).

• Converts n points of BCD data from (S) to BIN data in a batch and

stores the result to devices starting from (D).

Classification Symbol Description
