Mitsubishi Q2ACPU User Manual

App - 52
APPENDICES
Table App. 2.3. Special relay
Number Name Meaning Explanation
Set by
(When Set)
Corres-
ponding
ACPU
M9
Corresponding
CPU
SM320
Presence/absence of
SFC program
OFF : SFC program absent
ON : SFC program present
• Turns ON when an SFC program is registered.
• OFF when an SFC program is not registered.
S (Initial) M9100 QnA
SM321
Start/stop SFC
program
OFF : SFC program not
executed (stop)
ON : SFC program
executed (start)
• Initial value is set at the same value as SM320.
(Goes ON automatically if SFC program is present.)
• Turn this relay from ON to OFF to stop program
execution.
• Turn this relay from OFF to ON to resume program
execution.
S (Initial)/U
M9101form
at change
QnA
SM322
SFC program start
status
OFF : Initial start
ON : Resume start
• The SFC program starting mode in the SFC setting
of the PLC parameter dialog box is set as the initial
value.
AT initial start: OFF
At continued start: ON
S (Initial)/U
M9102form
at change
QnA
SM323
Presence/absence of
continuous transition
for entire block
OFF : Continuous transition
not effective
ON : Continuous transition
effective
Set the presence/absence of continuous transition for
the block where "Continuous transition bit" of the SFC
data device has not been set.
UM9103
QnA
SM324
Continuous transition
prevention flag
OFF : When transition is
executed
ON : When no transition
• OFF during operation in the continuous transition
mode or during continuous transition, and ON when
continuous transition is not executed.
• Always ON during operation in the no continuous
transition mode.
S (Instruction
execution)
M9104
QnA
S (Status change) New
QnA
SM325
Output mode at block
stop
OFF : OFF
ON : Preserves
Select whether the coil outputs of the active steps are
held or not at the time of a block stop.
• As the initial value, the output mode at a block stop in
the parameter is OFF when the coil outputs are OFF,
and ON when the coil outputs are held.
• All coil outputs go OFF when this relay is OFF.
• Coil outputs are preserved when this relay is ON.
S (Initial)/U M9196
QnA
SM326
SFC device clear
mode
OFF : Clear device
ON : Preserves device
Selects the device status when the stopped CPU is run
after the sequence program or SFC program has been
modified when the SFC program exists.
UNew
QnA
SM327
Output during end step
execution
OFF : Hold step output
turned OFF (cleared)
ON : Hold step output held
• Select the device status at the time of switching from
STOP to program write to RUN.(All devices except
the step relay)
S (Initial)/U New QnA
SM330
Operation mode for
low speed execution
type program
OFF : Asynchronous mode
ON : Synchronous mode
Select whether the low speed execution type program
will be executed in the asynchronous mode or in the
synchronous mode.
• Asynchronous mode (this relay is turned OFF.)
Mode in which the operation of the low speed
execution type program is performed continuously
within the excess time.
• Synchronous mode (this relay is turned ON.)
Mode in which the operation of the low speed
execution type program is not performed
continuously and operation is performed from the
next scan if there is excess time.
UNew QnA
