Mitsubishi Q2ACPU User Manual

App - 57
APPENDICES
(7) Debug
Table App. 2.8. Special relay
Number Name Meaning Explanation
Set by
(When Set)
Corres-
ponding
ACPU
M9
Corresponding
CPU
SM800
Sampling trace
preparation
OFF : Not ready
ON : Ready
• Goes ON when sampling trace is ready S (Status change) New QnA
SM801 Sampling trace start
OFF : Suspend
ON : Start
• Sampling trace started when this goes ON
• Suspended when OFF (Related special M all OFF)
UM9047 QnA
SM802
Sampling trace
execution in progress
OFF : Suspend
ON : Start
• Goes ON during execution of sampling trace S (Status change) M9046 QnA
SM803
Sampling trace trigger
OFF ON: Start
• Sampling trace trigger goes ON when this goes from
OFF to ON (Identical to STRA instruction execution
status)
UNew QnA
SM804
After sampling trace
trigger
OFF : Not after trigger
ON : After trigger
• Goes ON after sampling trace trigger S (Status change) New QnA
SM805
Sampling trace
completed
OFF : Not completed
ON : End
• Goes ON at completion of sampling trace S (Status change) M9043 QnA
SM806
Status latch
preparation
OFF : Not ready
ON : Ready
• Goes ON when status latch is ready S (Status change) New
QnA
SM807 Status latch command
OFF ON: Latch
• Runs status latch command U New
QnA
SM808
Status latch
completion
OFF : Latch not completed
ON : Latch completed
• Comes ON when status latch is completed. S (Status change) M9055
QnA
SM809 Status latch clear
OFF ON: Clear
• Enable next status latch U New
QnA
SM810
Program trace
preparation
OFF : Not ready
ON : Ready
• Goes ON when program trace is ready S (Status change) New
QnA
SM811 Start program trace
OFF : Suspend
ON : Start
• Program trace started when this goes ON
• Suspended when OFF (Related special M all OFF)
S (Status change) New
QnA
SM812
Program trace
execution under way
OFF : Suspend
ON : Start
• ON when program trace execution is underway U New
QnA
SM813 Program trace trigger
OFF ON: Start
• Program trace trigger goes ON when this goes from
OFF to ON (Identical to PTRA instruction execution
status)
S (Status change) New
QnA
SM814
After program trace
trigger
OFF : Not after trigger
ON : After trigger
• Goes ON after program trace trigger S (Status change) New
QnA
SM815
Program trace
completion
OFF : Not completed
ON : End
• Goes ON at completion of program trace S (Status change) New
QnA
SM820 Step trace preparation
OFF : Not ready
ON : Ready
• Goes ON after program trace registration, at ready S (Status change) New QnA
SM821 Step trace starts
OFF : Suspend
ON : Start
• Select whether execution of step trace is started or
suspended.
• When this goes ON, step trace is started
• Suspended when OFF (Related special M all OFF)
U
M9182form
at change
QnA
SM822
Step trace execution
underway
OFF : Suspend
ON : Start
• Goes ON when step trace execution is underway
• Goes OFF at completion or suspension
S (Status change) M9181
QnA
SM823 After step trace trigger
OFF : Not after trigger
ON : Is after first trigger
• Goes ON if even 1 block within the step trace being
executed is triggered.
• Goes OFF when step trace is commenced.
S (Status change) New
QnA
SM824 After Step trace trigger
OFF : Is not after all triggers
ON : Is after all triggers
• Goes ON if all blocks within the step trace being
executed are triggered.
• Goes OFF when step trace is commenced.
S (Status change) New
QnA
SM825 Step trace completed
OFF : Not completed
ON : End
• Goes ON at step trace completion.
• Goes OFF when step trace is commenced.
S (Status change) M9180
QnA
SM826 Sampling trace error
OFF : Normal
ON : Errors
• Goes ON if error occurs during execution of sampling
trace.
S (Status change) New QnA
SM827 Status latch error
OFF : Normal
ON : Errors
• Goes ON if error occurs during execution of status
latch.
S (Status change) New
QnA
SM828 Program trace error
OFF : Normal
ON : Errors
• Goes ON if error occurs during execution of program
trace.
S (Status change) New
QnA
