Mitsubishi Q2ACPU User Manual

3 - 19
3. SYSTEM CONFIGURATION
Product Name Model Name Description Applicable Model
Connector/terminal
block converter
module
A6TBXY36
For sink-type input module and
sink-type output module (standard type)
AX42(S1), AY42(S1/S3/S4), AH42
A6TBXY54
For sink-type input module and
sink-type output module. (2-wire type)
A6TBX70 For sink-type input module (3-wire type) AX42(S1), AH42
A6TBX36-E For source-type input module (standard type) AX82
A6TBY36-E For source-type output module (standard type) AY82EP
A6TBX54-E For source-type input module (2-wire type) AX82
A6TBY54-E For source-type output module (2-wire type) AY82EP
A6TBX70-E For source type input modules (3-wire type) AX82
Cable for connector/
terminal block
converter module
AC05TB For 0.5m (1.64ft.) sink module
A6TBXY36
A6TBXY54
A6TBX70
AC10TB For 1m (3.28ft.) sink module
AC20TB For 2m (6.56ft.) sink module
AC30TB For 3m (9.84ft.) sink module
AC50TB For 5m (16.40ft.) sink module
AC80TB
For 8m (314.96inch) sink module (Common
current: 0.5A or less)
AC100TB
For 10m (393.7inch) sink module (Common
current: 0.5A or less)
AC05TB-E For 0.5m (1.64ft.) source module
A6TBX36-E
A6TBY36-E
A6TBX54-E
A6TBY54-E
A6TBX70-E
AC10TB-E For 1m (3.28ft.) source module
AC20TB-E For 2m (6.56ft.) source module
AC30TB-E For 3m (9.84ft.) source module
AC50TB-E For 5m (16.40ft.) source module
Relay terminal
module
A6TE2-
16SRN
For sink-type output module
AY42, AY42-S1, AY42-S3, AY42-S4,
AH42
Cable for connecting
relay terminal module
AC06TE 0.6 m (1.97ft.) long
A6TE2-16SRN
AC10TE 1m (3.28ft.) long
AC30TE 3m (9.84ft.) long
AC50TE 5m (16.40ft.) long
AC100TE 10m (32.80ft.) long
