Mitsubishi Q2ACPU User Manual

App - 158
APPENDICES
(5) Monitor using GX Developer
Processing time in the case of monitoring by GX Developer
The processing time is added when monitoring by GX Developer.
(a) The following table shows the processing time when data register 64 points are
set for registration monitor:
(b) The following shows the processing time when monitor conditions are set.
(6) Local device
Processing time when the local device is used
The processing time is added when the local device is used.
Condition: loca device setting: 1 k point, n: number of program files
(7) Multiple program execution
Overhead time when executing each program that executes several programs in the
QnACPU.The processing time is added when several programs are executed..
Condition: n:number of program files
CPU Module Processing Time
Q2ACPU(S1) 0.46ms
Q3ACPU 0.35ms
Q4ACPU 0.18ms
CPU Module
Processing Time
Agreement in
Designated Step
Agreement in
Designated Device
Q2ACPU(S1) 0.38ms 0.38ms
Q3ACPU 0.29ms 0.29ms
Q4ACPU 0.15ms 0.15ms
CPU Module Processing Time
Q2ACPU(S1)
3.0 (n - 1) + 2.8ms
Q3ACPU
2.2 (n - 1) + 2.1ms
Q4ACPU
1.1 (n - 1) + 1.1ms
CPU Module Processing Time
Q2ACPU(S1)
0.21 nms
Q3ACPU
0.16 nms
Q4ACPU
0.08 nms
