7 - 4
7. AUTO REFRESH FUNCTION
*1 "n" is determined by the installation location of the master modules.
*2 When the total number of remote I/O station is odd, add 1 to the station number to obtain the
occupied storage devices.
*3 When the master module number setting column is made blank in parameter setting, auto
refresh can be used without this setting.
However, model name registration is required in the "I/O Assign". (MINI mode: AJ71PT32,
MINI-S3 mode: AJ71PT32-S3)
*4 When the input (X) is specified in the received data storage device, use the I/O number later
than the number used for the module loaded on the main base unit and the extension base
unit. When the I/O number usage range for the module loaded on the main base and the
extension base is used for input/output of the received data storage device, the CPU module
imports both the input ON/OFF data from the input module and the ON/OFF data from auto
refresh of MELSECNET/MINI-S3. Therefore, input (X) of the CPU module is not operated as
desired.
–
100
to
103
195
Faulty station
detection
M, L, B, T, ST, C, D, W, R, ZR,
none
(Bit device: multiples of 16)
• Sets the head device to store the faulty stations
detected data.
• MINI occupies 4 words; MINI-S3 occupies 5 words.
No setting
–
107
196
to
203
Error No. T, ST, C, D, W, R, ZR
• Sets the head device to store the error code at the
error occurrence.
• MINI occupies 1 word; MINI-S3 occupies (1 +
Number of remote terminal modules) words.
No setting
–4
Line error
check setting
(Line error)
• Test message sending (Test)
• OFF data sending (OFF)
• Immediate data transmission
before line errors
(Retention)
• Sets data sending method for verification of faulty
area when the line errors occur.
Retention
––
Operation at
CPU STOP
Stop/Continue
• Sets the operating status when the CPU module is
in the STOP state.
Stop
I/O signal
from a
master
module
Buffer memory
address of a
master module
Item Setting range Description Default value
