Mitsubishi RV-2F-D Series User Manual

3 Controller
Parallel I/O unit 3-87
Fig.3-37 ： Installing the parallel I/O unit (CR751)
RIOコネクタ
60
54 6
放熱、配線余裕
150
6
156
2-Ｍ ５ネ ジ
6
168
放熱余裕
128
(1 75 )
100
天
配線余裕
(4 0)
地
<2A-RZ361>
制御盤取付寸法
2A-RZ361の取付寸法
6
Installation dimensions of 2A-RZ361/371 (The controller outside installation.)
RIO connector
Upside
Wiring space
Heat radiation
space
2-M5 screw
Downside
Radiation/wiring
space
Control panel installation dimensions
Note) RV-2F series has operation panel.
<CR751 controller>
