Service Manual Mitsubishi SQ-Series diesel engines
Version 08/2004
PISTONS, CONNECTING RODS,
CRANKSHAFT AND CRANKCASE
ENGLISH
ENGINE MAIN PARTS
1. Connecting rod cap
2. Connecting rod bearing (lower half)
3. Main bearing cap
4. Main bearing (lower half)
5. Crankshaft
6. Main bearing (upper half)
7. Connecting rod
8. Connecting rod bearing (upper half)
9. Snap ring
10. Piston pin
11. Piston
12. No.1 ring
13. No.2 ring
14. Oil ring
15. Tappet
16. Crankcase
NOTE
When replacing the crankcase, carefully remove the
parts (such as the relief valve, etc.) from the
crankcase to reuse them at the time of reassembly.
