Service Manual Mitsubishi
SQ-Series diesel engines
V
ersion 08/2004
ENGLISH
FUEL FILTER (PAPER-ELEMENT
CARTRIDGE TYPE)
FUEL SYSTEM
FUEL SYSTEM
20
FUEL FIL
TER (P
APER-
ELEMENT CARTRIDGE
TYPE)
20.1
Disassembly and Inspection
1.
Element assem
bly
2.
Bracket
Figure 168
Disa
ssembly sequence
Air vent plug
Cracks,
damages
threads
Apply engine oil to
packing at installation
Clogged, cracked.
Replace every 500 service
hours.
2
1
99
101
