Service Manual Mitsubishi SQ-Series diesel engines
V
ersion 08/2004
FUEL INJECTION NOZZLES
ENGLISH
FUEL SYSTEM
FUEL SYSTEM
21
FUEL INJECTION
NOZZLES
21.1
Disassembly
1.
Retaining nut
2.
Nozzle tip assembly
3.
Piece
4.
Pin
5.
S
pring
6.
Washer
7.
Nozzle body
Figure 169
Disa
ssembly sequence
Check for wear
Check for carbon on tip
or in orifice
Check for wear
7
6
5
4
3
2
1
Check for defect
100
102
