Service Manual Mitsubishi SQ-Series diesel engines
V
ersion 08/2004
DISASSEMBLY, INSPECTION AND
REASSEMBLY
ENGLISH
INLET AND EXHAUST SYSTEM
INLET AND EXHAU
ST SYSTEM
12
DISASSEMBL
Y
,
INSPECTION AND
REASSEMBL
Y
1.
Air inlet elbow
2.
Gasket
3.
Inlet manifold
4.
Gasket
5.
Exhaust manif
old
6.
Gasket
Check for cracks
Replace
Check for cracks
Put gasket with
rounded side toward
exhaust manifold
when installing it
3
4
2
1
6
5
86
88
