1 Overview
No. 99MBE011A
1.2
SystemCongurationandNameofEachPart
The system conguration and the name of each part are shown below.
NC device
Feedback cable
and NC device
(prepared by user)
AT211 (scale unit and signal cable)
Tips
The one detector cable type (without connector) does not include the signal cable.

Fixing at multiple points
④
⑦
⑥
⑧
②
③
①
⑤
No. Name
①
Scale unit
②
Scale main unit
③
Detector
④
Detector cable
⑤
Signal cable
⑥
Scale alarm indication LED
⑦
Air supply inlet
⑧
Detector xing block
