Mitutoyo AT211 - Fixing at both Ends

46
6 Appendix
No. 99MBE011A
6.1.2 Fixing at both ends
E󰀨ec-
tive
length
Part No.
Accessory
Hex
socket
head cap
screw
M4 x 10
Hex
socket
head cap
screw
M4 x 25
Hex
socket
head cap
screw
M6 x 25
Plain
washer,
nominal 4
Small
round
Plain
washer,
nominal 6
Small
round
Spring
washer,
nominal 4
Spring
washer,
nominal 6
100
to
450
06AFU825A
7 2 2 2 2 2 2
500
to
1000
06AFU825B
1100
to
1500
06AFU825C
E󰀨ec-
tive
length
Part No.
Accessory
Nylon
clip
HP-4N
Nylon
clip
HP-6N
Nylon
clip
HP-10N
Interme-
diate sup-
port
Coun-
tersunk
screw
M3 x 5
Hex
socket
head cap
screw
M4 x 8
Spacer
set
Thick-
ness =
0.3, 0.4,
0.5, 0.6
mm
100
to
450
06AFU825A
5 5 2
0 0 0
1 for each
500
to
1000
06AFU825B 1 2 1
1100
to
1500
06AFU825C 2 4 2
