35
4Specication
No. 99MBE011A
Using ow rate adjustable
valves
Make adjustment with the air pressure, so that the air ow becomes 10
L/min—20 L/min (per scale unit).
NOTICE
Make sure not to supply a large amount of air before making ad-
justments. Otherwise, it may cause components to break thereby
resulting in malfunctions.
4.5.3 Air Supply Unit
The specications for recommended air devices and the manufacturer models are described in the
following.
If the specications are the same, you can use air equipment made by another company.
Estimated time of element replacement for each lter is one year.
Air dryer, and
main line air lter
Compressor side
Air device Scale
(1) (2) (3) (5)
(4)
No. Component
Appear-
ance
Specication
Part No.
Part No.
(Mitutoyo)
Manufac-
turer model
(1) Air lter
y Fluid: Compressed air
y Maximum operating pressure: 1.0
MPa
y Proof pressure: 1.5 MPa
y Maximum particle diameter (ltra-
tion): 5 µm
y Secondary oil concentration: -
-
F1000-8-W
(CKD)
(2) Oil mist lter
y Fluid: Compressed air
y Maximum operating pressure: 1.0
MPa
y Proof pressure: 1.5 MPa
y Maximum particle diameter (ltra-
tion): 0.01 µm
y Secondary oil concentration: 0.01
mg/m
3
or below
y Element replacement: One year
(6000 hours) or when pressure is
lowered to 0.1 MPa or lower
-
M1000-8-W
(CKD)
