Mitutoyo AT211 - 4.2 Cable Specifications

26
4Specication
No. 99MBE011A
4.2
CableSpecications
4.2.1 Signal Cable

Connection diagram
External view of signal cable Connection diagram of signal cable
D-sub connector Waterproof square
connector
15
610
18
915
3,4
11
1,2
13
5
6
7
8
9
10
15
PZ
PZ
+5V
F.G.
F.G.
PB
PB
PA
PA
GND
PZ
PZ
+5V
8
7
2
4
3
1,6
9
5
10
ALM
PB
PB
PA
PA
GND
Pin No. Signal name
D-sub connector
Cable material
Shielded wire
Connector case
Connector main unit
Pin No.Signal name
Waterproof square connector
Housing

D-sub connector
Applicable connector: HDAB-15S (Hirose Electric product or equivalent product (D-sub series) can be
used)
1
9
8
15
Pin No. Signal Pin No. Signal
1, 2, 13 0 V 8
PB
3, 4, 11 +5 V 9 PZ
5 PA 10 PZ
6 PA 12, 14 Unused
7 PB 15 F.G.
