12
2 Setup for Installation
No. 99MBE011A
2.2.3 Checking the Mounting Direction
Install the scale unit in the direction shown in the gure below. During installation, pay attention to the
unmounting direction of the detector cable. To reverse the unmounting direction of the detector cable,
reverse the scale unit itself.
Fixing at multiple points
Reverse unmounting direction
180-degree rotation
Normal mounting direction
Cable pulling direction
Cable pulling direction
Fixing at both ends
Reverse unmounting direction
180-degree rotation
Normal mounting direction
Cable pulling direction
Cable pulling direction
